Automatic VFFS Bagging Line for Dry Products(Multihead Weigher)
Automatic VFFS Bagging Line for Dry Products(Multihead Weigher)
Automatic VFFS Bagging Line for Dry Products(Multihead Weigher)
Automatic VFFS Bagging Line for Dry Products(Multihead Weigher)
Automatic VFFS Bagging Line for Dry Products(Multihead Weigher)
Share to:

Automatic VFFS Bagging Line for Dry Products(Multihead Weigher)

1)Air-Expend roll film loading, easy dismantle
2)Automatic alarm when roll is not enough
3)PLC control with touch screen operation
4)Double bet film pull driven by servo motor
5)Two servo motor driven for high speed running
6)Various bag size application by change bag former

Filling Range:
50-150g 100-300g 200-500g 300-700g 400-1000g
Product:
granule snack food candy biscuit sea food
Model:
BPW420 BPW422
Capacity:
60bags/min 120bags/min
Quantity:
Inquire Add to Basket

  • JIABOTECH
  • BPW
  • granule
  • automatic
  • weigher
  • servo motor
  • stable, top configuration
  • 50-1000G
  • 1%
pillow bag for granle
Food: pasta, chips, snack food, candy, confenctionery, peanut, biscuit, seed, sea food, pet food etc
Filling system: weigher
Typitcal Packaging Application:
-high production of pillow bag
-connect with vffs packer for bag in bag
-connect with carton packer for big box package
-connect with case packer for big case package

1) Air-Expend roll film loading, easy dismantle
2) Automatic alarm when roll is not enough
3) PLC control with touch screen operation
4) Double bet film pull driven by servo motor
5) Two servo motor driven for high speed running
6) Various bag size application by change bag former
Model: BP420 BP422
Machine size: 1050*1350*1700mm 2064*1850*1770mm
Machine weight 500KG 1100KG
Bag shape: Pillow Pillow
Bag width 80-200mm 100-200mm
Bag length 80-350mm 100-300
Bag volume: Max 2400cm3 Max 2400cm3
Output: Max 70bags/min Max 140Bags/min
Reel width: Max 420 Max 420
Outer diameter: Max 400mm Max 400mm
Inner diameter: Max 76mm Max 76mm
Connected load: 3KW 6KW
Power supply: 220V,3ph,60hz 220V,1ph,50hz
Air supply: 0.6Mpa, 0.15m3/min 0.6Mpa, 0.3m3/min

Potato-Chips 拷贝.jpg
pillow bag.png
-
