lavazza point coffee capsule filler

Features:
1.Auto cup feeding, storage more quantities
2.Auger Filler can full push out, easy clean
3.No cup, no fill
4.Servo Driven Cup feeder, more stable working
5.Auto detect for without cup, filter, coffee, lid etc
6.Premade lid or roll film cut for choice

Filling Range:
Product:
Model:
Capacity:
  • JIABOTECH
  • CFP-L
  • powder
  • automatic
  • auger filler
  • servo motor
  • stable, top configuration
  • 10-15g
  • 1%
ground coffee package into coffeee capsule
such as lavazza point, lavazza, nespresso, kee-fee, k cup,dolce gousto  etc
coffee-groundscco

Typitcal Packaging Application:
-high production of coffee capsule
-connect with vffs packer for capule in bag
-connect with doypack packer for capsule into standup pouch
-connect with carton packer for capsule into small carton


1. Auto cup feeding, storage more quantities
2. Auger Filler can full push out, easy clean
3. No cup, no fill
4. Servo Driven Cup feeder, more stable working
5. Auto detect for without cup, filter, coffee, lid etc
6. Premade lid or roll film cut for choice
7. Protect door for seal part satisfy safe standard
8. PLC Control, Touch screen easy operation

Model: CFP-2L CFP-2L
Fill Tool Auger Auger
Fill Range: 10-15G 10-15G
Fill Accuracy: ± 1 % ± 1 %
Capacity: Max: 25strokes/minute*2 Max: 25strokes/minute*4
Containers : Lavaza Point Lavaza Point
Container Size Diameter:50mm Diameter:50mm
Lid  Pre-cut Foil Pre-cut Foil
Hopper Capacity: 30L 60L
Air consumption 0.2m3/minute 0.4m3/minute
Air Pressure 0.6-0.8Mpa 0.6-0.8Mpa
Voltage 3 Phase, 220V, 60HZ 3 Phase, 220V, 60HZ
Power Consumption 4.7KW 7KW
Overall Dimension L3500×W830×2050mm L3500×W1630×2050mm
Net Weight 1200KG  1800KG

LAVAZZA SAMPLE
