jar can tin granule filling line for mixed nut, seed, peanut, almond, walnut, confectionery, cereal, candy etc
Typitcal Packaging Application: -high product of jar, can ,tin
-connect with capping machine, labelling machine, coding machine, shrink machine, patelizer etc
1. -Easy change bottle size by change nylone screw
2. -support handle for stable conveying container
3. -With bottom vibrating for high speed filling
4. -Take out support plate, easy for clean
5. -fill two bottle one time for high capacity 60fills/min
6. -Moveable weigher platform, height adjust 400-1600mm
Model | SW500D | SW5000D |
Products Filled: | Mixing Nut, Seed, peanut, almond, walnut, confectionery, snack, cereal |
Containers Filled: | Jar, Tin, Can, Bottle Etc |
Container Size | D:40-100mm, H:60-150mm | D:60-200mm, H:80-270mm |
Fill Speed: | 60 Fills/minute | 60 Fills/minute |
Fill Way | Weigher | Weigher |
Weigher Head | 10 | 14 |
Weigher hopper | 1.6L | 2.5L |
Fill Range: | ≤1000G | ≤2000g |
Fill Accuracy: | 0.5-2g |
Delivery Time | Within 10 weeks. | Within 10 weeks. |
Voltage | Single Phase, 220V,50/60HZ | Single Phase, 220V,50/60HZ |
Power Consumption | 2KW | 4.5KW |
Dimension (mm) | 2262×1250×2000 | 2813×1535×2500 |
Net Weight | 1000KG | 1400KG |
